JAC Junling V3 4m³ Vacuum Sewage Truck
Model 5070GXWH6
JAC Junling V3 4m³ Vacuum Sewage Truck configured for sewage suction and sanitation work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 4.2m³ |
|---|---|
| Tank dimensions | 4200 × 1900 × 1150 mm |
| Rated payload | 3360 kg |
| Overall dimensions | 5900 × 2000 × 2690 mm |
| Gross vehicle mass | 7360 kg |
| Curb weight | 3870 kg |
| Chassis model | HFC1071P33K1C7Z5 |
| Wheelbase | 3365 mm |
| Engine model | D25TCIF1 |
| Engine displacement | 2499 ml |
| Engine power | 110 kW |
| Horsepower | 149 hp |
| Tires | 7.00R16LT 14PR |
| Additional configuration | For suction of sewage in puddles, drains & sewers, core devices: tank+sewage suction system (tank with lifting function), total/effective cap.4.2/4.0m³, dims3600×φ1400mm (straight section×diameter3000× φ1400mm), side/rear protection Q235 (side bolted, rear welded), rear protection section (W×H)50×150mm, ground clearance400mm, ABS model VIE ABS-Ⅱ, optional CM4XL-4S/4M, chassis-optional cab, optional sewage suction pump style. |
