Dongfeng Tuyi 2m³ Vacuum Sewage Truck
Model CLT5042GXW6G
Dongfeng Tuyi 2m³ Vacuum Sewage Truck configured for sewage suction and sanitation work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 1.81m³ |
|---|---|
| Tank dimensions | 5350 × 1000 × 1000 mm |
| Rated payload | 1380 kg |
| Overall dimensions | 5350 × 1850 × 2250 mm |
| Gross vehicle mass | 4495 kg |
| Curb weight | 2985 kg |
| Chassis model | EQ1045SJ16DC |
| Wheelbase | 2800,3200 mm |
| Engine model | Q23-95C60 |
| Engine displacement | 2300 ml |
| Engine power | 70.95 kW |
| Horsepower | 96 hp |
| Tires | 185R15LT 8PR |
| Additional configuration | This vehicle is suitable for sewage suction and sewer dredging, with a total tank capacity of 1.81 cubic meters, an effective tank volume of 1.72 cubic meters, tank overall dimensions (length×width×height) of 5350×1000×1000mm, equipped with ABS, side and rear protection devices made of Q235 steel, only 2800mm wheelbase is selected, and different configurations such as sewage suction pipes, toolboxes, guardrails, ladders, warning lights can be optionally installed |
