Tree Trimming Trucks
Jiangling Kairui 8m³ Green Space Trimming Truck
Model 5080TYHJ6
Jiangling Kairui 8m³ Green Space Trimming Truck (5080TYHJ6) is configured for specialized fleet operations, with trimming speed of 1.2-6(km/h) and trimming height of 0.2-4.5(m).
Rated payload2215 kgChassis modelJX1083TK26Engine power112 kW
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated payload | 2215 kg |
|---|---|
| Overall dimensions | 6850 × 2150 × 3200 mm |
| Gross vehicle mass | 8210 kg |
| Curb weight | 5800 kg |
| Chassis model | JX1083TK26 |
| Wheelbase | 3815 mm |
| Engine model | JX4D306H |
| Engine displacement | 2892 ml |
| Engine power | 112 kW |
| Horsepower | 152 hp |
| Tires | 7.50R16LT 14PR |
| Body volume | 8m³ |
| Special notes | The upfit includes a boom trimming mechanism, fan and water tank for green-space pruning and collection. Side protection is welded aluminum alloy; rear protection is Q235B with bolted and welded connection, 100 × 50 mm section and 340 mm ground clearance. ABS model is VIE ABS-II. Box style is optional. The rear warning light is for work status only. |
| Trimming Speed | 1.2-6(km/h) |
| Trimming Height | 0.2-4.5(m) |
