Tree Trimming Trucks
Jiangling Kairui 3m³ Green Space Trimming Truck
Model 5081TYHJXE6
A Jiangling Kairui 3m³ Green Space Trimming Truck configured for landscaping maintenance.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated payload | 1425 kg |
|---|---|
| Overall dimensions | 6740 × 2165 × 3187 mm |
| Gross vehicle mass | 8200 kg |
| Curb weight | 6580 kg |
| Chassis model | JX1083TG26 |
| Wheelbase | 3360 mm |
| Engine model | JX4D306H |
| Engine displacement | 2892 ml |
| Engine power | 112 kW |
| Horsepower | 152 hp |
| Tires | 7.50R16LT 14PR |
| Body volume | 3.3m³ |
| Special notes | This vehicle uses 3360mm wheelbase, specially for green maintenance, pruning and collection of green crops; vehicle length is 6740mm with standard automatic water cannon, corresponding to front overhang 1864mm; vehicle length is 6609mm with optional new automatic water cannon, corresponding to front overhang 1733mm; box appearance and rear door appearance are optional; side protection is aluminum alloy (bolted connection), rear protection is Q345A (bolted connection, section 140×65mm, ground clearance 410mm); ABS and cab front face appearance are optional with chassis. |
| Trimming Speed | 1.2-6(km/h) |
| Trimming Height | 0.2-4.5(m) |
