Sewer Jetting Trucks
Dongfeng Tianjin 10m³ Sewer Jetter & Cleaning Truck
Model 5185GQX6HQ
Dongfeng Tianjin 10m³ Sewer Jetter & Cleaning Truck configured for sewer cleaning and pipeline dredging.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 9.45m³ |
|---|---|
| Tank dimensions | 5000 × 2300 × 1600 mm |
| Rated payload | 9005 kg |
| Overall dimensions | 8380 × 2550 × 3000 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 8800 kg |
| Chassis model | DFH1180EX8 |
| Wheelbase | 4700 mm |
| Engine model | B6.2NS6B230 |
| Engine displacement | 6200 ml |
| Engine power | 169 kW |
| Horsepower | 229 hp |
| Tires | 295/80R22.5 18PR |
| Additional configuration | The special devices of this vehicle are the tank and cleaning pump, which are used for cleaning urban sewers, pipeline sediments, and dredging dead-end mud ditches, and can also be used for cleaning pipelines and the ground. The effective volume of the tank is 9.0 cubic meters, the transportation medium is water, with a density of 1000 kg/m³. Both side and rear protections are welded with Q235B material. The section size of the rear protection device is 120mm× 50mm, and the height from the ground is 450mm. Equipped with ABS system, only chassis with a wheelbase of 4700mm are selected. The cab, tank style and rear device style, and chassis accessory air reservoir and urea tank installation position can be optionally installed with the chassis. Equipped with a driving recorder with satellite positioning function. |
