Fuel Tanker Trucks
Foton Auman 8×4 25m³ Oil Transport Truck
Model 5329GYYLB6A
Foton Auman 8×4 25m³ Oil Transport Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Transport medium | Gasoline |
|---|---|
| Tank / body volume | 25.8m³ |
| Tank dimensions | 5500 × 2350 × 1600 mm |
| Rated payload | 20400 kg |
| Overall dimensions | 11650 × 2550 × 3400 mm |
| Gross vehicle mass | 32000 kg |
| Curb weight | 11470 kg |
| Chassis model | BJ1329Y6GRL-09 |
| Wheelbase | 2100+4400+1350 mm |
| Engine model | X11NS6B360 |
| Engine displacement | 10500 ml |
| Engine power | 265 kW |
| Horsepower | 360 hp |
| Tires | 12.00R20 18PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 8900×2300×1600mm; The side protection is bolt-connected with aluminum alloy material, the rear protection is bolt-connected with Q235 material (cross-section 80×140mm, 490mm above the ground); It is equipped with EBS system, a speed limiter (limited to 80km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, rear axle air suspension, and can be optionally equipped with ETC, tank ladder and toolbox styles and other configurations. |
