Mercedes-Benz Arocs (8×4) Heavy-duty Rescue Fire Truck
A heavy-duty rescue fire truck with supplied lifting, monitoring and rescue-equipment provisions for complex incident response.
Rescue crane29-ton folding boom craneCrane working span16.5 mFire monitor flow rate2880 L/minRated payload10000 kgChassis modelBenz Arocs 4158 (8 × 4)Engine power425 kW
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rescue crane | 29-ton folding boom crane |
|---|---|
| Crane working span | 16.5 m |
| Fire monitor flow rate | 2880 L/min |
| Rated payload | 10000 kg |
| Overall dimensions | 12000 × 2550 × 3950 mm |
| Gross vehicle mass | 40000 kg |
| Curb weight | 30000 kg |
| Chassis model | Benz Arocs 4158 (8 × 4) |
| Wheelbase | 1750+4600+1350 mm |
| Engine model | OM473LA.6-55 |
| Engine displacement | 15600 ml |
| Engine power | 425 kW |
| Horsepower | 578 hp |
| Tires | 385/65R22.5 (front) / 315/80R22.5 (rear) |
| Special notes | Heavy-duty rescue fire truck supplied with a rear 29-ton folding boom crane, electric winch, generator set, and breaking, detection and rescue equipment. The catalog identifies use at complex incidents including large building collapses and chemical accidents. |
