Fuel Tanker Trucks
Dongfeng D9 12m³ Refueling Truck
Model 5180GYY5
Dongfeng D9 12m³ Refueling Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 12.23m³ |
|---|---|
| Tank dimensions | 8000 × 2080 × 1300 mm |
| Rated payload | 9650 kg |
| Overall dimensions | 8500 × 2500 × 3175 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 8155 kg |
| Chassis model | EQ1181LJ9BDEWXP |
| Wheelbase | 4700 mm |
| Engine model | ISB180.50 |
| Engine displacement | 5900 ml |
| Engine power | 132 kW |
| Horsepower | 179 hp |
| Tires | 10.00R20 18PR |
| Additional configuration | Dongfeng D9 chassis, Fast 8-speed transmission, 295/80 vacuum tires, equipped with air conditioner, front disc brake, speed limiter, power windows, EBS, air suspension, collision warning, lane departure warning and tire pressure monitoring; volume 12.6cubic meters (effective tank volume 13cubic meters), made of Q235B steel plate (cylinder, head and baffle all 5mm thick), single-compartment with 1 tank opening on top, full set of European standard components, 1 subsea valve with automatic closing device, 80/60 special oil pump (pump-in/out available), high-flow fuel dispenser with 15m thickened reel and gun, including rear ladder, manual guardrail, toolbox, rear bumper and side guardrail, manufactured to new standards with regular standard configurations, providing gasoline medium tank inspection report, chassis certificate, vehicle certificate and registration invoice. |
