Dongfeng Small Duolika 4m³ Refueling Truck
Model 5072GLYD4
Dongfeng Small Duolika 4m³ Refueling Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 4.1m³ |
|---|---|
| Tank dimensions | 3050 × 1750 × 1150 mm |
| Rated payload | 3240 kg |
| Overall dimensions | 5995 × 1960 × 2400 mm |
| Gross vehicle mass | 7300 kg |
| Curb weight | 3865 kg |
| Chassis model | DFA1070SJ35D6 |
| Wheelbase | 3300 mm |
| Engine model | 4B28BTCI |
| Engine displacement | 2834 ml |
| Engine power | 70 kW |
| Horsepower | 95 hp |
| Tires | 7.00-16 14PR |
| Additional configuration | This vehicle has an effective tank volume of 4.1m³, with tank external dimensions of 3050×1750×1150mm; The protection material is Q235A carbon steel, and the rear protection is 400mm above the ground; It can be optionally equipped with refueling machines, is equipped with a speed limiter (limited to 80km/h), adopts a chassis with radial tires and front-mounted exhaust pipes, and is equipped with an ABS system. |
