Foam Fire Trucks
Sinotruk Howo 5 Ton Compressed Air Foam Fire Truck
Model 5180GXFAP50/H6
This vehicle is a compressed air foam fire truck, with special devices including a compressed air foam system, lighting system, and winch.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 5.125m³ |
|---|---|
| Tank dimensions | 2120 × 1400 × 1430 mm |
| Rated payload | 5150 kg |
| Overall dimensions | 8620 × 2510 × 3620 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 12400 kg |
| Chassis model | ZZ5207TXFV471GF5 |
| Wheelbase | 4700 mm |
| Engine model | MC07H.35-60 |
| Engine displacement | 7360 ml |
| Engine power | 257 kW |
| Horsepower | 349 hp |
| Tires | 295/80R22.5 18PR |
| Additional configuration | This vehicle is a compressed air foam fire truck, with special devices including a compressed air foam system, lighting system, and winch. The water tank volume is 4.05 cubic meters, Class A foam liquid tank volume is 0.291 cubic meters, and Class B foam liquid tank volume is 0.784 cubic meters. It adopts an integrated side protection structure. The rear protection device is made of Q235A material, with a cross-section (width×height) of 60×120mm, bolt-connected to the vehicle, and the rear protection is 455mm above the ground. Optional rear devices without stretching devices, automatic charging device surrounding process styles, and red strobe lights can be installed. The cab can be optionally installed with the chassis. |
