Shacman Delong L5000 Drainage Rescue Truck
Model 5165TPSL6
Shacman Delong L5000 Drainage Rescue Truck is configured for emergency pumping and drainage work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 8540 × 2500 × 3400 mm |
|---|---|
| Gross vehicle mass | 16000 Kg |
| Curb weight | 15805 Kg |
| Chassis model | SX1189LA1F1C |
| Wheelbase | 4500 mm |
| Engine model | B6.2NS6B230 |
| Engine displacement | 6200 ml |
| Engine power | 169 kW |
| Horsepower | 229 hp |
| Tires | 10.00R20 11PR |
| Special notes | The drainage pump is the main special device for emergency pumping and drainage operations. Cab and front-face styles are optional with the chassis; side and rear protection are replaced by body components, with 450 mm rear ground clearance. ABS corresponds to relevant models. The listed vehicle length, wheelbase, front overhang and rear overhang combinations are 8540/4500/1340/2700, 8740/4700/1340/2700, 8740/4700/1450/2590, 9140/5100/1340/2700 and 9140/5100/1450/2590 mm. Leaf-spring suspension and the specified tire model are required; appearance and internal structure are optional. |
| Additional configuration | ith the chassis, the side and rear protection are replaced by the vehicle body components, and the rear height of the vehicle is 450mm from the ground; ABS corresponds to relevant models; The special device is mainly the drainage pump, used for drainage emergency operations; The corresponding relationship of vehicle length/wheelbase/front overhang/rear overhang is (mm): 8540/4500/1340/2700, 8740/4700/1340/2700, 8740/4700/1450/2590, 9140/5100/1340/2700, 9140/5100/1450/2590; This model only adopts leaf spring suspension and only adopts the specified tire model; Appearance style and internal structure are optional |
