Rescue Utility Trucks
Maxus V80 Short-axis Rescue Vehicle
Model EHY5040XXHS6QT
Maxus V80 Short-axis Rescue Vehicle supports emergency rescue, field repair and engineering response work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 4950, 5160, 5035 × 1998 × 2337, 2540 mm |
|---|---|
| Gross vehicle mass | 3800 kg |
| Curb weight | 2190 kg |
| Chassis model | SH6521A2DB |
| Wheelbase | 3100 mm |
| Engine model | SC20M125.1Q6; SC20M139Q6; SC20M147Q6 |
| Engine displacement | 1996 ml |
| Engine power | 93; 102; 108 kW |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 215/75R16LT |
| Axles | 2 |
| Maximum speed | 160, 150, 100 km/h |
| Rated passengers | 3-6 |
