Prisoner Transport Vehicles
SAIC Maxus V80 Long-axis Prison Van
Model EHY5041XQCS6QT
SAIC Maxus V80 Long-axis Prison Van is configured for secure supervised transport in law-enforcement operations.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 6110, 6070, 6035, 5860, 5700, 5785 × 1998 × 2560 mm |
|---|---|
| Gross vehicle mass | 3800 kg |
| Curb weight | 2640, 2560, 2360 kg |
| Chassis model | SH6571A4DB-N |
| Wheelbase | 3850 mm |
| Engine model | SC20M147Q6 |
| Engine displacement | 1996 ml |
| Engine power | 108 kW |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 215/75R16LT |
| Axles | 2 |
| Maximum speed | 155 km/h |
| Rated passengers | 10-15 |
