Ambulances
Jiangling Fushun Mid-axis Ambulance
Model EHY5041XJHJ6QT
A 5-9 occupant mid-axis ambulance configuration based on the Jiangling Fushun platform.
Chassis modelJX6555T-M6
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated passengers | 5-9 |
|---|---|
| Overall dimensions | 5670,5495 × 1974 × 2750,2665,2560,2480,2380 mm |
| Gross vehicle mass | 3550 kg |
| Curb weight | 2720,2560,2310 kg |
| Chassis model | JX6555T-M6 |
| Wheelbase | 3360 mm |
| Engine model | JX4D20A6H |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 215/75R16LT,215/75R16C |
| Axles | 2 |
| Maximum speed | 160,100 km/h |
