Ambulances
Foton G7 Short Wheelbase Ambulance
Model 5031XJH6QT
A 6-7 occupant short-wheelbase ambulance configuration based on the Foton G7.
Chassis modelBJ6489B1DXA-K1
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated passengers | 6-7 |
|---|---|
| Overall dimensions | 4860 × 1695 × 2430 mm |
| Gross vehicle mass | 2860 kg |
| Curb weight | 2000 kg |
| Chassis model | BJ6489B1DXA-K1 |
| Wheelbase | 2570 mm |
| Engine model | 4K22D4M |
| Fuel type | Gasoline Gasoline |
| Emission standard | China 6 (China 6 (GB 18352.6-2016)) |
| Tires | 195R15C,195/70R15LT |
| Axles | 2 |
| Maximum speed | 150 km/h |
